Ash Omni Core (obsolete)

2D Measurement, Annotation & Graticules: Intuitive on screen full 2D patented measurement application. Simply draw measurements, shapes and add annotations onto a live or static image and save direct to internal memory or external storage options. Features include: point to point, diameter, angle, adjustable X-Y grid, shapes and annotation to accommodate a multitude of samples specifications.

Graticule: creation allows samples to be analysed against on-screen digital templates with set tolerance limits. It also enables quick go/no-go defect analysis. This improves efficiency in high-volume sample through-put inspection

Image Stacking:View a sample with different layers all in focus at the same time. Omni automatically captures several images from 2 to 12 at different focal depths and creates an image based on the sharpest regions from each of these separate captures.

Comparator Overlay: This app allows the user to create an image overlay of a master image to identify defects by overlaying and flashing the live sample image against the stored master image. Enables rapid identification of differences between gold sample and test samples. Improved accuracy and usability in addition to improved workflow speed.

Comparator Side by Side: Visually compare your live sample image to a stored master image in the form of a split screen. Add notes through annotation and save the comparison image for documentation and traceability. Enables rapid identification of differences between gold sample and test samples.

Calibration Tracking: All Omni’s are factory calibrated before shipping. No time is wasted performing recalibrations between changing magnifications.

Customize Workflow: Create custom workflows to standardize and control inspection processes. Customize With Integrated Apps Flexibility to configure software with a range of applications to suit your needs and budget.

Compact Footprint: Integrated software avoids the expense and task of qualifying a PC.

Connected: Save time by documenting directly to server or cloud network for traceability.

Calibrated For Industry: Calibrated to ISO 17025 standard. No need to calibrate. Maintains calibration while zooming providing trust in our measurement capability.

Repeatable Measurement: Automatic edge detection for repeatable and reproducible patented measurements that reduce variability between users.
