Motic serie BA210

The BA210 is designed for both educational and teaching environments delivering a new higher level of optical performance

The new BA210 series is setting a new standard in microscope performance through inprovements both in optical and mechanical features. Designed to be used in Educational Life Science, Medical as well as a variety of biological applications, this new microscope is built around Motic's complete understanding of the daily demands placed on the standard educational microscope.

Student proof features together with a new generation of EF-N Plan Achromatic objectives provide a fully corrected intermediate image for crisp and clear visual and digital results.

BA210 binocular with Halogen illumination
BA210 binocular with LED illumination
BA210 trinocular with Halogen illumination
BA210 trinocular with LED illumination
BA210E

The BA210 is a robust student instrument that brings professional, repeatable image quality results to all of its intended applications.

30° inclined Binocular / Trinocular Siedentopf head for comfortable viewing while seated, rotates 360°
Interpupillary distance adjustment between 55-75mm
Widefield eyepieces N-WF10X/20mm with diopter adjustment on both eyepieces
Reversed quadruple nosepiece with click stops for precise magnification changes
CCIS EF-N Plan Achromatic objectives 4X/0.10, 10X/0.25, 40X/0.65 – Spring, 100X/1.25 – Spring/Oil
Coaxial coarse and fine focusing system with 2 micron minimum increment with tension adjustment
Vertical travel range 25mm
Large 140mm X 135mm mechanical stage with low-position coaxial controls. Travel range 76 X 50mm.
Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slider slot.
Collector lens assembly with screw-on filter holder
Quartz Halogen illumination 6V/30W with intensity control or LED illumination
