Nikon Metrology LC15Dx Laser scanner (obsolete)

Thanks to the most advanced laser scanner technology, the LC15Dx is closing the gap with tactile probe accuracy. In tests comparable to ISO 10360 the LC15Dx achieved the accuracy expected when using a CMM with a tactile probe.

Nikons unique ESP3 technology maintains accuracy, speed and data quality by adapting the laser settings in real-time. Manufacturers gain a better appreciation of the dimensional quality of their products without compromising on cycle times.

Key benefits

• Viable alternative to a tactile probe for an increasing number of high precision CMM applications.
• Measure a wider variety of parts, geometry and materials more efficiently, including small details and fragile parts.
• A complete 3D visualisation of dimensional quality using Colour Mapping, with the detail necessary for further analysis.

Specifications

• Probing error (MPEp) 1 2.5μm (0.0001in)
• Multi-stylus test (MPEAL) 2 6μm (0.00024in)
• Resolution (point spacing) 22μm (0.00087in)
• Data acquisition (approx.) 70,000 points/sec
• Points per line (approx.) 900
• Measuring temperature range 18-22°C (64.4-71.6°F)
• Operating temperature range 10-40°C (50-104°F)
• Warm-up time 0 (zero) seconds
• Weight 370g (13oz)
• Ingress Protection IP30
• Power 110/240Vac, 50/60Hz 5A
• Enhanced Scanner Performance (ESP3) √
• Daylight filter √
• Probe head compatibility3 PH10M, PH10MQ, CW43, PHS
• Laser type Class 2 (660nm)
