Surtronic® Duo II – Portable Surface Roughness Tester

The Taylor Hobson Surtronic® Duo II is a high-performance, portable surface roughness tester designed to deliver fast and reliable measurements of surface finish directly on-site in production, workshop, or inspection environments. With its robust construction, intuitive operation, and advanced metrology technology, the Surtronic® Duo II provides precise roughness values at the push of a button — ideal for quality control, process monitoring, and production inspection.

Fast and Accurate Surface Roughness Measurement

The Surtronic® Duo II measures multiple surface parameters, including Ra, Rz, Rp, Rv, and Rt, and displays them instantly on a clear 2.4″ color LCD with intuitive menus. Its rechargeable battery allows flexible measurements on virtually any surface, anytime and anywhere.

The device can also be used with HSE Slips software to assess floor safety or precisely monitor manufacturing processes.

Key Features

• One‑button operation – complete, traceable roughness values at the press of a button
• Handheld & portable – ideal for direct use on parts in production, workshop, or laboratory
• 2.4″ color LCD display – clear presentation of roughness values and profile graphs
• Bluetooth technology – wireless data transfer between the measuring unit and control/display module
• Profile graph output – visual representation of the measurement for quick analysis
• Removable units – display/control module can be detached from the measuring unit for flexible handling
• Rechargeable battery & USB – long battery life and easy charging via mini-USB
• Robust diamond stylus & piezo pickup – durable stylus and motorized traverse for accurate and repeatable measurements

How It Works

A high-quality diamond stylus is drawn across the surface by a precision motorized traverse. Vertical displacements over peaks and valleys are detected by a piezoelectric pickup and converted into electrical signals. These signals are digitally processed to calculate the roughness parameters directly and according to standardized methods.

Typical Applications

The Surtronic® Duo II is especially suitable for:

• Process control – grinding, milling, turning, honing, polishing, and extrusion
• Heavy industry and plant engineering – shipbuilding, pipelines, sheet metal, and structural components
• Aerospace – turbine blades, shafts, and composite materials
• Other applications – printing rollers, floor surface analysis, adhesives, and glass surfaces

Why Choose the Surtronic® Duo II?

The Surtronic® Duo II combines portability, durability, and high precision in a compact, easy-to-use instrument. It enables fast on-site decisions, eliminates complex setups, and ensures repeatable results — all backed by Taylor Hobson’s renowned expertise in metrology.
