M3 Measuring software
Offering greater functionality than the M2, the Digital-video-based M3 is multi-touch software that can pan and zoom with the touch of a finger.
It works with active part views and live video feeds as well as a conventional mouse interface.
The M3’s custom “Eye Measure” probe captures complex edges generated by a finger path drawn on the touch screen.
It also has “Measure Logic” probe intelligence to provide instant feature determination and measurement with a single touch.
Along with a host of other features, the M3 offers simple machine/camera calibration with popular video measurement system correction methods.
Remark: the M3 can be fully integrated in any Nikon Measuring systems MM, Ryf-Ryeo RMM Systems as well as Systems from Vision Engineering like a Kestrel, Falcon or Hawk.
The most innovative measuring software for the use of coordinate measuring systems. As original equipment and for retrofitting. The needed functionality can be configured individually.
Specification
- 2 to 5 axis (X, Y, Z, Q, Zoom)
- Measuring point acquisition by crosshair, clever video tools, touch probe systems and laser
- Multi touch probe capability
- Measure, construct and define 2D and 3D regular geometries
- Measure polynomes with the blob tool
- Stitch images to a super image
- DXF overlay in live image
- Contour tracking and BestFit
- Position detection
- Manual operation or CNC with motor control
- Light control up to 8 channels
- Tolerance check according to DIN / ISO with tolerance chart
- Part programming with palletizing and program loops for video and touch probe measurement
- Launch program with barcode reader
- Image archiving (BMP, JP2, JPG, PNG)
- Program creation from DXF file
