Nikon Metrology NEXIV VMZ-R4540 (obsolete)

The CNC Video Measuring System "NEXIV VMZ-R4540" is capable of accurately measuring the dimensions and shapes of high density and multi-layered electronic components.

Key Features

Laser AF

Designed to detect the surfaces of thin transparent materials, the new Laser AF works with the same high speed and high accuracy as the VMR series Laser AF.

New Laser AF The new sensor detects both the top and back of surfaces.

8-sector ring light system with three incident angles

Episcopic, diascopic and ring illuminations employ white LEDs and provide stability and long life. The new ring light system has three incident angles designed for correct edge capture.

Streamlined and logical software

Redesigned user interface with Wizard makes it easy for beginners to operate the system and create automated measurement programs.
