Unbeatable image sharpness
Only those who see clearly can measure precisely. Our 4K camera with first-class optics and precise zoom brings every detail to the point - for reliable and precise measurement results.

Magnification up to 300x (standard)
Alternatively, machines with magnification up to 1000x are possible - whether 300x, 500x, 750x or the maximum: with Toollense, even the smallest micro-tools can be inspected precisely and safely.

Never measure incorrectly again
Automatic zoom detection - the Toollense software automatically recognises the selected zoom and also adjusts the lighting perfectly. This makes precision the standard.

Intuitive and user-friendly software
Our intuitive and user-friendly software enables every user to take precise measurements quickly and easily. With a clearly structured user interface and simple functions, measuring is child's play, regardless of experience or technical background.

Ergonomic design
Toollense is designed to be user-friendly and easy to use.

Solid base for maximum precision
A solid base is crucial for consistently precise measurements. Toollense is designed to fulfil these requirements: Toollense is precisely aligned on three points and, with its 7 cm thick, stable and high-precision granite plate, guarantees the foundation for long-term measurement accuracy and high reliability. Toollense is therefore ideal for precise requirements directly in production or in the measuring room.

---

Sharp: thanks to world-leading imaging
The 4K camera built into ToolLense is the world's best camera on the market and conjures up the sharpest images on the monitor. With the 300x optical zoom, you can inspect cutting tools from a diameter of 0.8 mm. An optional lens with 700x magnification is available for micro tools, allowing cutting tools in the micro range from a diameter of 0.05 mm to be measured.

Sharp: thanks to innovative & optimised lighting
Light is the most important factor in achieving the best image quality. Precise edge detection is only possible with sharp edges and perfect illumination. That is why ToolLense places the greatest possible emphasis on innovative and perfect lighting. Toollense offers automatic backlighting, which adjusts the brightness completely independently when the zoom factor is changed. The frontal ring light is divided into 4 areas of 90 degrees each. These 90 degree areas can be switched on and off individually. The front ring light can be moved lengthways and adjusted to the optimum position. There is also a freehand light - should there be a lack of light for your cutting tool.
All 3 lights are infinitely adjustable manually.

Unbeatable sharpness = unbeatable precision
The extremely sharp image combined with perfect illumination enables high-precision measurements. Cutting tools can be measured manually and with high precision using the axes via the crosshairs. Alternatively, ToolLense also offers the option of carrying out measurements in the 0.001 mm range with its innovative and highly precise edge detection. Angles, lengths, diameters, widths etc. on cutting tools such as milling cutters or drills can be measured quickly and easily.
